AG 500SC



Power output: 500 watts @ 4 ohms, 250 watts @ 8 ohms

Inputs: One ¼" Input jack with Active/Passive switch

Tone controls:

Bright: +5dB >4kHz shelving

Treble: +/- 13dB @ 4kHz shelving

High Mid: +/- 14dB @ 800Hz peaking

Low Mid: +/- 14dB @ 400Hz peaking

Bass: +/- 18dB @ 40Hz shelving

Deep: +6dB <100Hz shelving

FX Loop: Series/Parallel; Send pot is Push/Pull for Line or Instrument level; Return pot is Push/Pull for Parallel or Series operation.

Outputs: Two Neutrik Speakon and two ¼" speaker outputs, XLR balanced D.I. out with Pre and Post EQ switch, Tuner output.

Mute: Push button with LED (footswitch optional)

Dimensions: 43.2(W)× 25.4(D)×8.9(H)cm

Rack Size: 2U spaces

Weight: 8.2kg

※付属のラックマウント・アダプターを取り付ける際にハンドルの取り外しが必 要となります。ハンドルの取り外し方法についてはこちらをご確認ください。
